Software Architecture

This section provides comprehensive documentation of Scopy’s software architecture using interactive diagrams. The architecture is documented using Structurizr DSL and includes both application and deployment views.

Interactive Diagram Workspaces

Application Architecture

The application architecture workspace provides detailed views of Scopy’s internal structure, including:

  • Infrastructure Layer: Application coordination, preferences, logging, and crash reporting

  • Core Business Logic: Device management, plugin system, and package management

  • UI Framework: Window management, common widgets, and presentation components

  • Plugin Packages: M2K, SWIOT, AD936X, ADRV9002, IMU, PQMon and generic plugins

  • Supporting Libraries: IIO utilities, GNU Radio widgets, and common utilities

Tip

View Interactive Application Architecture

Open Application Architecture Diagrams

Explore 15+ component views showing relationships between infrastructure, core business logic, UI components, and plugin packages.

Deployment Architecture

The deployment architecture workspace documents the CI/CD pipeline and multi-platform build process:

  • Build Infrastructure: GitHub Actions and Azure DevOps workflows

  • Docker Environments: Pre-configured build containers for each platform

  • Platform Support: Windows (MinGW), Linux (Flatpak, AppImage), macOS (DMG), ARM platforms

  • Artifact Distribution: Automated package creation and GitHub Releases distribution

Tip

View Interactive Deployment Architecture

Open Deployment Architecture Diagrams

Understand the complete build and deployment pipeline from source code to distributed packages across multiple platforms.

System Context

Overview

Scopy is a multi-functional software toolset with strong capabilities for signal analysis, designed to work with Analog Devices hardware evaluation boards.

External Systems

Hardware Integration

  • ADI Hardware Devices: ADALM2000, AD936X, ADRV9002, AD-SWIOT1L-SL, and other evaluation boards

  • IIO Framework: Linux Industrial I/O subsystem providing hardware abstraction layer

Software Ecosystem

  • GNU Radio: Signal processing backend for advanced DSP operations

  • Operating Systems: Cross-platform support for Linux, Windows, and macOS

  • File System: Local and network storage for data, configurations, and logs

Core Components

Application Infrastructure

Application Coordinator

Central orchestration of application startup, shutdown, and lifecycle management

Device Management

Unified interface for hardware device discovery, connection, and communication

Plugin System

Dynamic loading and management of device-specific functionality through packages

Package Manager

Installation and distribution system for plugin packages

Preferences Management

Centralized configuration storage and user settings persistence

Plugin Architecture

Scopy uses a modular plugin-based architecture where functionality is organized into specialized packages:

Generic Plugins

  • ADC Plugin - Interface with IIO ADCs using buffer mechanisms

  • DAC Plugin - Interface with IIO DACs using buffer or DDS mechanisms

  • DataLogger Plugin - Data monitoring and logging capabilities

  • Debugger Plugin - IIO context examination and attribute modification

  • JESD Status Plugin - JESD204 interface status monitoring

  • Register Map Plugin - Direct device register access

Device-Specific Packages

  • M2K Package: ADALM2000 (M2K) device support with oscilloscope, signal generator, logic analyzer

  • SWIOT Package: AD-SWIOT1L-SL platform support for industrial IoT applications

  • AD936X Package: AD936X transceiver family support for RF applications

  • ADRV9002 Package: ADRV9002 Jupiter transceiver with dual-channel RF capabilities

  • IMU Package: Inertial measurement unit evaluation and analysis tools

  • PQMon Package: Power quality monitoring and analysis capabilities

CI/CD Pipeline

Build Infrastructure

GitHub Actions Workflows

  • Windows MinGW builds with MSYS2 environment

  • Linux Flatpak sandboxed package creation

  • Linux AppImage portable application builds

  • ARM64/ARMHF cross-compilation for embedded platforms

  • Ubuntu development builds for testing

Azure DevOps

  • macOS DMG package creation using Homebrew dependencies

Docker Infrastructure

  • Pre-configured build environments for each target platform

  • Consistent dependency management across build systems

  • Reproducible builds with version-controlled containers

Deployment Targets

Platform Coverage

  • Windows: Setup executable (.exe) installer

  • Linux: Flatpak packages (.flatpak) and AppImage executables (.AppImage)

  • macOS: Disk image packages (.dmg)

  • ARM platforms: Cross-compiled AppImage executables for ARM64 and ARMHF

Distribution

  • Automated artifact publishing to GitHub Releases

  • Version-controlled release management

  • Multi-platform simultaneous deployment

Source Documentation

The architecture diagrams are generated from version-controlled Structurizr DSL files:

  • docs/architecture/diagrams/app_diagrams/workspace.json - Application architecture definition

  • docs/architecture/diagrams/deployment_diagrams/workspace.json - Deployment architecture definition

These files are automatically processed during documentation builds to generate the interactive diagram websites accessible through the links above.
